Fuji Electric differential pressure sensor with seal – FKD

Pressure sensors

Fields of application

With a diaphragm seal, a pressure sensor can be used for a wide range of applications: liquid flow measurement, gas flow measurement, vapor flow measurement, liquid level measurement in a container, liquid density measurement, or pressure measurement at low or high temperatures.

Features

  • Precise measurement even at low pressures
  • Accessible sensor installation and reading
  • Diaphragm seals can be mounted on all transmitter types
  • A wide range of possible applications
  • SPECIFICATIONS
  • AVAILABLE MODELS
  • DOCUMENTS

SPECIFICATIONS

  • Housing

    L- or T-shaped housing

  • Measuring ranges (kPa) [e.max.]

    32
    130
    500
    3000
    20000
    3000

  • Weight per kg (without indicator)

    9-19

  • Accuracy

    ± 0.065 %

  • Materials in contact with the process

    Stainless steel 316L, Hastelloy-C, Monel, Tantalum, Titanium, Zirconium

  • Case materials

    Low-copper aluminum alloy with polyester coating, or 316 L stainless steel

  • Membrane materials

    Stainless steel 316 L
    Hastelloy-C
    Monel
    Titanium
    Zirconium
    Stainless steel 316 L and Gilding

  • Stability

    ± 0.2% of full scale for 10 years.

  • Elevation / Deletion

    From -100 to +100% of maximum scale

  • Scale setting range

    1 to 1/100 of maximum scale

  • Measurement cycle

    40ms

  • Communication protocol

    HARTTM 7 communication protocol

  • Process temperature

    From +40° to +120°C (versions for higher temperatures are available)

  • Ambient temperature

    From -40° to +85 °C

  • Power supply

    10.5-45V DC

  • Output signal / Load resistance

    4-20 mA / 250 Ω typical

  • Damping

    Configurable between 0.04 and 32 secs

  • Zero and span adjustment

    Via external sensor screw, local three-button display or HARTTM protocol

  • Electrical connections

    M20×1.5" / 1/2 - 14 NPT / Pg13.5

  • Options

    Digital indicator, degreasing treatment, oxygen service, chlorine service, additional stainless steel identification plate

AVAILABLE MODELS

Product code Electrical connection Measurement scale Approval Separator model Price
FKDT65V6-2XC1Y-0L/SA6VYGY/SA6VYGY 1/2"NPT From 0 to 1300 mbar ATEX - Explosion-proof by enclosure Flange ANSI-300LB 3''- ISO PN 50 DN 80
FKDT65V6-2XC1Y-0L/SA7VYGY/SA7VYGY 1/2"NPT From 0 to 1300 mbar ATEX - Explosion-proof by enclosure Flange ANSI-300LB 4''- ISO PN 50 DN 100
FKDT65V6-2KC1Y-0L/SA6VYGY/SA6VYGY 1/2"NPT From 0 to 1300 mbar ATEX - Intrinsic safety Flange ANSI-300LB 3''- ISO PN 50 DN 80
FKDT65V6-2KC1Y-0L/SA7VYGY/SA7VYGY 1/2"NPT From 0 to 1300 mbar ATEX - Intrinsic safety Flange ANSI-300LB 4''- ISO PN 50 DN 100
FKDT65V6-2AC1Y-0L/SA6VYGY/SA6VYGY 1/2"NPT From 0 to 1300 mbar Without approval Flange ANSI-300LB 3''- ISO PN 50 DN 80
FKDT65V6-2AC1Y-0L/SA7VYGY/SA7VYGY 1/2"NPT From 0 to 1300 mbar Without approval Flange ANSI-300LB 4''- ISO PN 50 DN 100
FKDT63V6-2XC1Y-0L/SA6VYGY/SA6VYGY 1/2"NPT From 0 to 320 mbar ATEX - Explosion-proof by enclosure Flange ANSI-300LB 3''- ISO PN 50 DN 80
FKDT63V6-2XC1Y-0L/SA7VYGY/SA7VYGY 1/2"NPT From 0 to 320 mbar ATEX - Explosion-proof by enclosure Flange ANSI-300LB 4''- ISO PN 50 DN 100
FKDT63V6-2KC1Y-0L/SA6VYGY/SA6VYGY 1/2"NPT From 0 to 320 mbar ATEX - Intrinsic safety Flange ANSI-300LB 3''- ISO PN 50 DN 80
FKDT63V6-2KC1Y-0L/SA7VYGY/SA7VYGY 1/2"NPT From 0 to 320 mbar ATEX - Intrinsic safety Flange ANSI-300LB 4''- ISO PN 50 DN 100
FKDT63V6-2AC1Y-0L/SA6VYGY/SA6VYGY 1/2"NPT From 0 to 320 mbar Without approval Flange ANSI-300LB 3''- ISO PN 50 DN 80
FKDT63V6-2AC1Y-0L/SA7VYGY/SA7VYGY 1/2"NPT From 0 to 320 mbar Without approval Flange ANSI-300LB 4''- ISO PN 50 DN 100
FKDT66V6-2XC1Y-0L/SA6VYGY/SA6VYGY 1/2"NPT From 0 to 5000 mbar ATEX - Explosion-proof by enclosure Flange ANSI-300LB 3''- ISO PN 50 DN 80
FKDT66V6-2XC1Y-0L/SA7VYGY/SA7VYGY 1/2"NPT From 0 to 5000 mbar ATEX - Explosion-proof by enclosure Flange ANSI-300LB 4''- ISO PN 50 DN 100
FKDT66V6-2KC1Y-0L/SA6VYGY/SA6VYGY 1/2"NPT From 0 to 5000 mbar ATEX - Intrinsic safety Flange ANSI-300LB 3''- ISO PN 50 DN 80
FKDT66V6-2KC1Y-0L/SA7VYGY/SA7VYGY 1/2"NPT From 0 to 5000 mbar ATEX - Intrinsic safety Flange ANSI-300LB 4''- ISO PN 50 DN 100
FKDT66V6-2AC1Y-0L/SA6VYGY/SA6VYGY 1/2"NPT From 0 to 5000 mbar Without approval Flange ANSI-300LB 3''- ISO PN 50 DN 80
FKDT66V6-2AC1Y-0L/SA7VYGY/SA7VYGY 1/2"NPT From 0 to 5000 mbar Without approval Flange ANSI-300LB 4''- ISO PN 50 DN 100
FKDW65V6-2XC1Y-0L/SA6VYGY/SA6VYGY M20×1.5 From 0 to 1300 mbar ATEX - Explosion-proof by enclosure Flange ANSI-300LB 3''- ISO PN 50 DN 80
FKDW65V6-2XC1Y-0L/SA7VYGY/SA7VYGY M20×1.5 From 0 to 1300 mbar ATEX - Explosion-proof by enclosure Flange ANSI-300LB 4''- ISO PN 50 DN 100
FKDW65V6-2KC1Y-0L/SA6VYGY/SA6VYGY M20×1.5 From 0 to 1300 mbar ATEX - Intrinsic safety Flange ANSI-300LB 3''- ISO PN 50 DN 80
FKDW65V6-2KC1Y-0L/SA7VYGY/SA7VYGY M20×1.5 From 0 to 1300 mbar ATEX - Intrinsic safety Flange ANSI-300LB 4''- ISO PN 50 DN 100
FKDW65V6-2AC1Y-0L/SA6VYGY/SA6VYGY M20×1.5 From 0 to 1300 mbar Without approval Flange ANSI-300LB 3''- ISO PN 50 DN 80
FKDW65V6-2AC1Y-0L/SA7VYGY/SA7VYGY M20×1.5 From 0 to 1300 mbar Without approval Flange ANSI-300LB 4''- ISO PN 50 DN 100
FKDW63V6-2XC1Y-0L/SA6VYGY/SA6VYGY M20×1.5 From 0 to 320 mbar ATEX - Explosion-proof by enclosure Flange ANSI-300LB 3''- ISO PN 50 DN 80
FKDW63V6-2XC1Y-0L/SA7VYGY/SA7VYGY M20×1.5 From 0 to 320 mbar ATEX - Explosion-proof by enclosure Flange ANSI-300LB 4''- ISO PN 50 DN 100
FKDW63V6-2KC1Y-0L/SA6VYGY/SA6VYGY M20×1.5 From 0 to 320 mbar ATEX - Intrinsic safety Flange ANSI-300LB 3''- ISO PN 50 DN 80
FKDW63V6-2KC1Y-0L/SA7VYGY/SA7VYGY M20×1.5 From 0 to 320 mbar ATEX - Intrinsic safety Flange ANSI-300LB 4''- ISO PN 50 DN 100
FKDW63V6-2AC1Y-0L/SA6VYGY/SA6VYGY M20×1.5 From 0 to 320 mbar Without approval Flange ANSI-300LB 3''- ISO PN 50 DN 80
FKDW63V6-2AC1Y-0L/SA7VYGY/SA7VYGY M20×1.5 From 0 to 320 mbar Without approval Flange ANSI-300LB 4''- ISO PN 50 DN 100
FKDW66V6-2XC1Y-0L/SA6VYGY/SA6VYGY M20×1.5 From 0 to 5000 mbar ATEX - Explosion-proof by enclosure Flange ANSI-300LB 3''- ISO PN 50 DN 80
FKDW66V6-2XC1Y-0L/SA7VYGY/SA7VYGY M20×1.5 From 0 to 5000 mbar ATEX - Explosion-proof by enclosure Flange ANSI-300LB 4''- ISO PN 50 DN 100
FKDW66V6-2KC1Y-0L/SA6VYGY/SA6VYGY M20×1.5 From 0 to 5000 mbar ATEX - Intrinsic safety Flange ANSI-300LB 3''- ISO PN 50 DN 80
FKDW66V6-2KC1Y-0L/SA7VYGY/SA7VYGY M20×1.5 From 0 to 5000 mbar ATEX - Intrinsic safety Flange ANSI-300LB 4''- ISO PN 50 DN 100
FKDW66V6-2AC1Y-0L/SA6VYGY/SA6VYGY M20×1.5 From 0 to 5000 mbar Without approval Flange ANSI-300LB 3''- ISO PN 50 DN 80
FKDW66V6-2AC1Y-0L/SA7VYGY/SA7VYGY M20×1.5 From 0 to 5000 mbar Without approval Flange ANSI-300LB 4''- ISO PN 50 DN 100

DOCUMENTS

  • Certificate: SIL FCX-AIV-V6 series pressure transmitters

    198.3 KB

    Download

  • Certificate: UKCA declaration of conformity FCX-AIV-V6 series pressure transmitters

    1.22 MB

    Download

  • Manual: Pressure transmitters FCX-AIV V6

    7.97 MB

    Download

  • Software: Windows USB/HART modem drivers for pressure transmitter FCX

    63.57 KB

    Download

  • Software: Configuration of pressure transmitter FDT DTM pack for FCX V4 V5 VG V6

    7.06 MB

    Download

  • Datasheet : Diaphragm seals pressure transmitters FCX-AIV V6 FKB FKD FKM

    5.23 MB

    Download

  • Brochure: Pressure transmitters FCX-AIV V6 series

    6.65 MB

    Download

  • Brochure : Pressure transmitters

    15.17 MB

    Download

  • Brochure: Measures for energy and the environment

    4.01 MB

    Download
