Guenther varžinis PT100 temperatūros jutiklis 74-WTH

Guenther resistance PT100 temperature sensor 74-WTH

Temperature sensors

Fields of application

74-WTH series temperature sensors are small, vibration and shock resistant, designed for installation in equipment and process lines. Models with straight or tapered tip, with or without thread, suitable for temperatures up to +400 °C.

Features

  • Resistant to Vibrations

  • Quick wiring connection

  • Small dimensions

  • High tightness (IP protection)

  • SPECIFICATIONS
  • AVAILABLE MODELS
  • DOCUMENTS

SPECIFICATIONS

  • Connector plug

    M12 male thread
    Angle plug according to DIN EN 175301

  • Process connection

    Without
    Thread G 1/2 A
    Thread G 1/4 A
    Thread G 3/8 A
    Thread M18 x 1.5
    Thread M20 x 1.5
    Small flange DN 25 KF
    Other as required

  • Measuring insert

    Pt100 class A
    Pt100 class B
    Pt100 class B 1/3
    Pt100 class B 1/5
    Pt1000 class A
    Pt1000 class B
    Nickel (Ni 100, ...)
    NTC/PTC

    Circuit:
    1x 2-wire
    1x 3-wire
    1x 4-wire
    2x 2-wire

  • Type of construction

    Tapered to a diameter of 3 - 6 mm to increase sensor speed

AVAILABLE MODELS

Product code Price
74-WTH

DOCUMENTS

  • Documentation: 74-WTH Temperature sensors with a machine connector

    575.22 KB

    Download
