UWT Vibranivo® vibrating level sensor – VN 7130

SPECIFICATIONS

• Measuring principle

  Vibration (Fork)

• Measuring task

  Point level measurement

• display_vn

  FSH, FSL
  Hysteresis
  LED spalvos
  Sensibility
  Time delay
  Window

• Version

  Pipe extension

• Medium

  Fluids

• Mounting position

  Top
  Horizontal
  In down Pipes
  In a Bypass

• Ambient temperature

  -40 ... 75°C, -40 ... 176°F

• Process temperature

  -40°C … +150°C (-40°F … +302°F)

• Process pressure

  -1 bar … +40 bar (-14.5 psi … +580 psi)

• Minimum sensitivity

  > 0,5 g/cm3

• Housing type

  Compact

• Housing material

  Stainless steel 1.4404 (316L)

• Housing protection rating

  IP69
  Type 6P

• Threaded connection

  ≥ G 1/2"
  ≥ G 3/4"
  ≥ NPT 3/4"
  NPT ½"

• Flange connection

  ≥ DN25

• Hygienic fittings

  ≥ Triclamp 1"
  Įleidžiama suvirinama jungtis (G ¾" versijoje)

• Wetted materials

  Stainless steel 1.4404 (316L)

• Mechanical load

  Tube: 80 Nm

• Min. immersion length

  115 mm, 4.53"

• Max. immersion length

  4000 mm, 157"

• Power supply

  19 ... 230V AC/DC
  10 ... 30V DC

• Signal output

  Transistor PNP
  IO-Link
  2-wire without contact

• Certificates

  CE
  General purpose
  FMc
  UKCA

• Hygienic / Pharma

  EC 1935/2004
  FDA
  EHEDG (Type EL)

• Ship approval

  ---

• Overfill protection

  WHG

• SIL qualification

  ---

• Further approvals

  ---

• Optical indicator

  LED, multicolor
